tesa® 62510

tesa® 62510 is a double sided PE foam tape for mounting applications. It consists of a highly conformable PE foam backing and a tackified acrylic adhesive.

Category:

Feature

  • High ultimate adhesion level for a reliable bonding performance
  • Skin contact certification according to ISO 10993-5 and ISO 10993-10
  • Fully outdoor suitable: UV, water and ageing resistant
  • Conformable PE foam core with high inner strength
  • Suitable for automatic and manual module assembly
    Easy solar module assembly due to a high foam compression rate

Application

  • General mounting applications
  • Mounting of trims and profiles
  • Solar module frames

Additional Information

Liner variants:

  • PV0 brown glassine paper (71 µm)
  • PV13 transparent PET film (50 µm)
  • PV15 blue PE film (100 µm)

Peel Adhesion:

  • immediately: foam splitting on steel
  • after 14 days: foam splitting on steel, ABS, Aluminum, PC, PET, PS, PVC

tesa® 62510 is recognized by UL as photovoltaic polymeric material (QIHE2).

tesa® 62510 has been tested by TÜV Rheinland, Germany. The test confirms the longterm adhesion performance after IEC 61215 climate tests and a 85°C temperature resistance.

The temperature resistance (short/long) of tesa® 62510 has been approved according to tesa test method under static load.
